Handel Power Flanged Butterfly Valve Triple Eccentric Hard Seal Ring PN1.0/1.6 Mpa

  • 1
  • 2

Brand Name : Y

Model Number : D43H-10/16C

Place of Origin : China

MOQ : 10 pcs

Price : Negotiable

Payment Terms : T/T

Supply Ability : 10000 pcs per year

Delivery Time : 5-8 work days

Packaging Details : wooden box 1200*1100*1100

product name : Flanged Butterfly Valve

pressure : 1.0/1.6 Mpa

body material : WCB

Type : Triple eccentric

Sealing face : Stainless steel

Opening mode : Handel

Connection : flanged end

temperature : -29 to 425 ℃

stem material : 2Cr13

Yoke : WCB

Contact Now

Handel Power Triple Eccentric Hard Seal Ring PN1.0/1.6 Mpa Flanged Butterfly Valve

Introduction

The butterfly plate of the butterfly valve is installed in the diameter direction of the pipeline. In the cylindrical channel of the butterfly valve body, the disc butterfly plate rotates around the axis with a rotation angle of 0 ° - 90 °. When it rotates to 90 °, the valve is fully open

Usage

This valve is suitable the pipelines of water, oil etc. It can adjust and cut off the fluid.

Dimensions

mm L D D1 b-f Z-фd H H1
50 108 165 125 2-20 4-ф18 82 384
65 112 185 145 2-20 4-ф18 92 402
80 114 200 160 2-20 8-ф18 100 407
100 127 220 180 2-22 8-ф18 110 434
125 140 250 210 2-22 8-ф18 125 506
150 140 285 240 2-24 8-ф22 140 546
